0x603F/0 Error code

Index Sub-index
0x603F 0
The object
In DS402, a large number of possible error codes are specified. The following list
shows the relationship between the error code displayed internally by the frequency
inverter and on the KP500 control unit, and the error secured in object
Inverter
Error
F00 xx
F01 xx
F02 xx
F03 xx
F04 xx
F05 xx
F07 xx
F08 xx
F13 xx
Fyy xx
If the value 1000 (= generic error) appears as the DS402 error code, then the invert-
er error code can be read via parameter
rameter contains the error code in the product-internal format.
The assignment table of the error code can be taken from the operating instructions.
In the emergency message, the error code of the frequency inverter is transmitted in
bytes 4 ... 7 and the DS402 error code in bytes 0 and 1. Please refer to object
COB-ID Emergency Message
07/13
Meaning
Error code
error code
is used to store the last error that occurred.
DS402
Error code
00 00 No error has occurred
23 10 Frequency inverter has been overloaded
42 10 Case temperature outside the temperature limits
41 10 Inside temperature outside the temperature limits
43 10 Motor temperature too high or sensor defective
23 40 Motor phase current above the current limit
32 10 DC link voltage outside the voltage range
Electronic voltage
51 11 Electronic voltage outside the voltage range
23 30 Earth fault on frequency inverter output
10 00 Other error reports
for further explanations.
