12.5.5

0x6042/0 Target velocity [rpm]

Index Sub-index
0x6042 0
Object works in:
• Motion Control:
Velocity mode
o
Non motion Control (conf. ≠ x40)
•
target velocity
Object
velocity is interpreted as a speed with the unit RPM. The inverter's internal reference
frequency is calculated from the target velocity in RPM taking into account parameter
No. of Pole Pairs
The parameter
applications (configuration = x40) only the data set 1 is used.
Non motion control applications (configuration ≠ x40) sometimes have more than one
motor connected to the inverter (only one at a time, switched over by contactor).
These motors may have a different no. of pole pairs. The entry in
373 is then different in the four data sets. After change-over of the motor, the object
target velocity
ence frequency of the inverter using the correct no. of pole pairs.
No.
0x6042
In Non motion Control configurations (conf. ≠ x40) the target velocity reference value is
product-internally connected to the Reference line value. This reference value is
combined with the internal reference frequency value from the frequency reference
value channel in the input of the ramp function (see chapter 14.3.3 "Reference value /
actual value").
74
Meaning
Target velocity
is the speed reference value for the frequency inverter.
373.
No. of Pole Pairs
must be written at least once in order to recalculate the internal refer-
Parameter
Object
Target velocity
CM-EtherCAT
Data type
Integer16
Object doesn't work in:
• Motion Control:
Table Travel record mode
o
Profile Velocity mode
o
Profile Positioning mode
o
Homing mode
o
Interpolated mode
o
Cyclic Sync Position mode
o
Cyclic Sync Velocity mode
o
Move away from Limit Switch
o
Electronic Gear: Slave
o
373 has four different data sets. In motion control
Min.
-32768
Access Map Def.-Val
rw Rx 0
Target
No. of Pole Pairs
Setting
Max.
32767
07/13
