15 Annex

15.1
The various control functions and methods and the hardware of the frequency inverter
contain functions that continuously monitor the application. In addition to the mes-
sages documented in the manual, the following warning messages are activated by
the Profibus-DP communication module CM-PDPV1.
The warning messages are given via parameter
the following scheme:
Bit no. Warning code
Note:
15.2
The fault code that is stored after a fault occurs is made up of the fault group FXX
(high Byte, hexadecimal) followed by the code number XX (low Byte, hexadecimal).
F20
F26
* This message only appears whenever
In addition to the fault messages stated, there are further fault messages used for
internal purposes only and which are not listed here. If you receive any fault messag-
es which are not listed, please contact us by phone.
54
54

Warning messages

0 0x0001 Warning Ixt
1 0x0002 Warning Short Term - Ixt
2 0x0004 Warning Long Term - Ixt
3 0x0008 Warning Heat sink Temperature Tc
4 0x0010 Warning Inside Temperature Ti
5 0x0020 Warning Limit
6 0x0040 Warning Init
7 0x0080 Warning Motor Temperature
8 0x0100 Warning Mains Failure
9 0x0200 Warning Motor Protective Switch
10 0x0400 Warning Fmax
11 0x0800 Warning Analog Input MFI1A
12 0x1000 Warning Analog Input A2
13 0x2000 Warning System bus
14 0x4000 Warning Udc
15 0x8000 Warning V-Belt
The meaning of the individual warnings are described in detail in the op-
erating instructions.

Fault messages

Code
62 Profibus OFF (communication connection to DP Master lost) *
02 Communication watchdog CM-PDPV1 / inverter controller
CM-PDPV1
Warnings
Warning messages
Meaning
Communication fault
Meaning
Profibus Error Reaction
CM-PDPV1
270, bit-coded according to
393 = 1 – Error.
