Annex

13 Annex

13.1 Warning Messages

The warning messages are given via parameter
scheme.
Warnings
Parameter
tool VPlus.
Warnings
Use Parameter
Bit-No. Warning Code
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
13 0x2000
14 0x4000
15 0x8000
1) 2)
: Bit 0 "Warning Ixt" is set,
− if Bit 1 "Warning Short Term Ixt" or
− if Bit 2 "Warning Long Term Ixt" is set.
Warnings
In Parameter
Example:
Message
Warning Ixt
Short Term Ixt
Warning Limit Heat Sink Tem-
perature
Warning Limit Motor Tempera-
ture
Sum
06/2010
269 shows the warnings in clear text on the operator panel and the PC software
270 to access the warning codes via VABus.
Warning Messages
Description
Warning Ixt
Warning Short Time Ixt
Warning Long Time Ixt
Warning Heat Sink Temperature Tk
Warning Inside Temperature Ti
Warning I-Limit
Warning Init
Warning Motor Temperature
Warning Mains Phase Failure
Warning Motor Protective Switch
Warning Fmax
Warning Analog Input MFI1A
Warning Analog Input MFI2A
Warning Systembus Slave in Fault
Warning Udc
Warning V-Belt
270 several warnings can be set at the same time.
Warning Code
0x0001
0x0002
0x0008
0x0080
0x008B
Warnings
270, bit-coded according to the following
1) 2)
1)
2)
Set on Short Term or Long Term Ixt.
VABus Agile
Comment
