Via Objects 0x5F11, 0x5F12, 0x5F13 and 0x5F14 four different Phasing profile can be
created. The Phasing Profile is selected via Control word bits 12 and 13.
Phasing select
Bit 13
0
0
1
1
Alternatively the parameters 1125, 1126 and 1127 can be used instead of the Ob-
jects. The 4 data sets of the parameters correspond to the 4 Objects. Usage of the
Objects will write the parameters in RAM (data set 6...9).
0x5F11/1
0x5F12/1
0x5F13/1
0x5F14/1
0x5F11/2
0x5F12/2
0x5F13/2
0x5F14/2
0x5F11/3
0x5F12/3
0x5F13/3
0x5F14/3
62
Phasing Profile
Bit 12
0 1 (0x5F11)
1 2 (0x5F12)
0 3 (0x5F13)
1 4 (0x5F14)
Object
Phasing 1: Offset
Phasing 2: Offset
Phasing 3: Offset
Phasing 4: Offset
Phasing 1: Speed
Phasing 2: Speed
Phasing 3: Speed
Phasing 4: Speed
Phasing 1: Acceleration
Phasing 2: Acceleration
Phasing 3: Acceleration
Phasing 4: Acceleration
CM-EtherCAT
Parameter
1125.1
Phasing: Offset
1125.2
1125.3
1125.4
1126.1
Phasing: Speed
1126.2
1126.3
1126.4
1127.1
Phasing: Acceleration
1127.2
1127.3
1127.4
