12.4.3

0x3003/0 Digital Out set values

Index Sub-index
0x3003 0
Via object 0x3003 there are 5 digital sources available for use with parameters, which
require digital values.
The value of object 0x3003 is limited from 0 to 31.
No.
0x3003/0 Digital Out set values
Digital outputs use these sources as operation mode 90 ... 94
1 ... 5
respectively inverted as 190 ... 194
parameter
outputs is arbitrary.
Example:
Function
Op. Mode Digi-
tal Output 3
The sources can be chosen directly by the selection of 810...814
1 ... 5
from the parameters choice list. This can be used e.g. for direct setting of Bool-
ean inputs.
07/13
Meaning
Digital Out set values
Bit Source no.
0 810
1 811
2 812
3 813
4 814
Object
Op. Mode Digital Output 1
Parameter no.
532
CM-EtherCAT
Data type
Unsigned8
Object 0x3003
Source name
Obj 0x3003 Digout 1
Obj 0x3003 Digout 2
Obj 0x3003 Digout 3
Obj 0x3003 Digout 4
Obj 0x3003 Digout 5
Min.
0
inv. Obj 0x3003 DigOut 1 ... 5
).
530 The mapping of this object bits to the
Choice list (excerpt)
0 - OFF
1 - Ready or Standby Signal
2 - Run Signal
...
43 - External Fan
90 - Obj 0x3003 Digout 1
91 - Obj 0x3003 Digout 2
92 - Obj 0x3003 Digout 3
93 - Obj 0x3003 Digout 4
94 - Obj 0x3003 Digout 5
...
143 - inv. External Fan
190 - inv. Obj 0x3003 Digout 1
191 - inv. Obj 0x3003 Digout 2
192 - inv. Obj 0x3003 Digout 3
193 - inv. Obj 0x3003 Digout 4
194 - inv. Obj 0x3003 Digout 5
...
Access Map Def.-Val
rw Rx 0
Operation mode
Digital output
90/190
91/191
92/192
93/193
94/194
Max.
31 (= 0x1F)
Obj 0x3003 DigOut
(see e.g.
Obj 0x3003 DigOut
