12
12.1
The various control methods and the hardware of the frequency inverter include func-
tions which continuously monitor the application. In addition to the messages docu-
mented in the frequency inverter operating instructions, further warning messages are
activated by the RS232/RS485 communication modules CM-232/CM-485.
The bit-coded warning reports are issued via parameter
the following pattern:
Bit no. Warning code
1) 2)
Note:
Note:
Example:
Warning Ixt
Short-Term Ixt
Warning Limit Heat Sink Temperature
Warning Motor Temperature
80
80
Annex
Warning Messages
Warning Messages
0
0x0001
Warning Ixt
Warning Short-Term Ixt
1
0x0002
Warning Long-Term Ixt
2
0x0004
3
0x0008
Warning Heat Sink Temperature Tk
0x0010
Warning Inside Temperature Ti
4
Warning I-limit
5
0x0020
Warning Init
6
0x0040
Warning Motor Temperature
7
0x0080
Warning Phase Failure
8
0x0100
Warning Motor Protection Switch
9
0x0200
10
0x0400
Warning Fmax
Warning Analog Input MFI1A
11
0x0800
Warning Analog Input A2 (EM-S1INA)
12
0x1000
Warning System Bus Slave Failure
13
0x2000
Warning Udc
14
0x4000
Warning V-belt
15
0x8000
Bit 0 "Warning Ixt" is always set
if bit 1 "Warning Short-Term Ixt" or
−
−
if bit 2 "Warning Long-Term Ixt" is set.
The individual warnings are described in detail in the frequency inverter
operating instructions.
Warnings
In parameter
same time.
Message
Modbus Instruction manual
Modbus Instruction manual
Description
1) 2)
1)
2)
270 several warnings can be displayed at the
Warning
code
Is set in Short-Term Ixt or Long-Term Ixt
0x0001
0x0002
0x0008
0x0080
Total
0x008B
Warnings
270 according to
Remarks
05/08
