Analog-to-digital converter (ADC)
16.13.8

ADC watchdog low threshold register (ADC_LTR)

Address offset: 0x28
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
Reserved
Bits 31:12 Reserved, must be kept cleared.
Bits 11:0 LT[11:0] Analog watchdog low threshold
These bits are written by software to define the low threshold for the Analog Watchdog.
16.13.9

ADC regular sequence register 1 (ADC_SQR1)

Address offset: 0x2C
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
SQ16_
SQ15[4:0]
0
rw rw rw rw
Bits 31:24 Reserved, must be kept cleared.
Bits 23:20 L[3:0]: Regular channel sequence length
These bits are written by software to define the total number of conversions in the regular channel
conversion sequence.
0000: 1 conversion
0001: 2 conversions
.....
1111: 16 conversions
Bits 19:15 SQ16[4:0]: 16th conversion in regular sequence
These bits are written by software with the channel number (0..17) assigned as the 16th in the
conversion sequence.
Bits 14:10 SQ15[4:0]: 15th conversion in regular sequence
Bits 9:5 SQ14[4:0]: 14th conversion in regular sequence
Bits 4:0 SQ13[4:0]: 13th conversion in regular sequence
376/501
27 26 25
11 10 9
rw rw rw
27 26 25
Reserved
11 10 9
rw rw rw
24 23 22 21
Reserved
8 7 6 5
LT[11:0]
rw rw rw rw
24 23 22 21
L[3:0]
8 7 6 5
SQ14[4:0]
rw rw rw rw
20 19 18 17
4 3 2 1
rw rw rw rw
20 19 18 17
SQ16[4:1]
4 3 2 1
SQ13[4:0]
rw rw rw rw
