RM0008
Table 56.
Endpoint
Type
OUT
As it happens with double-buffered bulk endpoints, the registers used to implement
Isochronous endpoints are forced to be used as unidirectional ones. In case it is required to
have Isochronous endpoints enabled both for reception and transmission, two registers
must be used.
The application software is responsible for the DTOG bit initialization according to the first
buffer to be used; this has to be done considering the special toggle-only property that these
two bits have. At the end of each transaction, the CTR_RX or CTR_TX bit of the addressed
endpoint register is set, depending on the enabled direction. At the same time, the affected
DTOG bit in the register is hardware toggled making buffer swapping completely software
independent. STAT bit pair is not affected by transaction completion; since no flow control is
possible for Isochronous transfers due to the lack of handshake phase, the endpoint
remains always '11' (Valid). CRC errors or buffer-overrun conditions occurring during
Isochronous OUT transfers are anyway considered as correct transactions and they always
trigger an CTR_RX event. However, CRC errors will anyway set the ERR bit in the register
to notify the software of the possible data corruption.
17.5.5
Suspend/Resume events
The USB standard defines a special peripheral state, called SUSPEND, in which the
average current drawn from the USB bus must not be greater than 500 µA. This requirement
is of fundamental importance for bus-powered devices, while self-powered devices are not
required to comply to this strict power consumption constraint. In suspend mode, the host
PC sends the notification to not send any traffic on the USB bus for more than 3mS: since a
SOF packet must be sent every mS during normal operations, the USB peripheral detects
the lack of 3 consecutive SOF packets as a suspend request from the host PC and set the
SUSP bit to '1' in register, causing an interrupt if enabled. Once the device is suspended, its
normal operation can be restored by a so called RESUME sequence, which can be started
from the host PC or directly from the peripheral itself, but it is always terminated by the host
PC. The suspended USB peripheral must be anyway able to detect a RESET sequence,
reacting to this event as a normal USB reset event.
The actual procedure used to suspend the USB peripheral is device dependent since
according to the device composition, different actions may be required to reduce the total
consumption.
A brief description of a typical suspend procedure is provided below, focused on the USB-
related aspects of the application software routine responding to the SUSP notification of
the USB peripheral:
1.
Set the FSUSP bit in the register to 1. This action activates the suspend mode within
the USB peripheral. As soon as the suspend mode is activated, the check on SOF
Isochronous memory buffers usage (continued)
DTOG bit
Packet buffer used by the
value
USB peripheral
ADDRn_RX_0 / COUNTn_RX_0
0
buffer description table
locations.
ADDRn_RX_1 / COUNTn_RX_1
1
buffer description table
locations.
USB full speed device interface (USB)
Packet buffer used by the
application software
ADDRn_RX_1 / COUNTn_RX_1
buffer description table
locations.
ADDRn_RX_0 / COUNTn_RX_0
buffer description table
locations.
395/501
