RM0008
13.4.12

Encoder interface mode

To select Encoder Interface mode write SMS='001' in the TIMx_SMCR register if the
counter is counting on TI2 edges only, SMS='010' if it is counting on TI1 edges only and
SMS='011' if it is counting on both TI1 and TI2 edges.
Select the TI1 and TI2 polarity by programming the CC1P and CC2P bits in the TIMx_CCER
register. When needed, you can program the input filter as well.
The two inputs TI1 and TI2 are used to interface to an incremental encoder. Refer to
Table 39. The counter is clocked by each valid transition on TI1FP1 or TI2FP2 (TI1 and TI2
after input filter and polarity selection, TI1FP1=TI1 if not filtered and not inverted,
TI2FP2=TI2 if not filtered and not inverted) assuming that it is enabled (CEN bit in
TIMx_CR1 register written to '1'). The sequence of transitions of the two inputs is evaluated
and generates count pulses as well as the direction signal. Depending on the sequence the
counter counts up or down, the DIR bit in the TIMx_CR1 register is modified by hardware
accordingly. The DIR bit is calculated at each transition on any input (TI1 or TI2), whatever
the counter is counting on TI1 only, TI2 only or both TI1 and TI2.
Encoder interface mode acts simply as an external clock with direction selection. This
means that the counter just counts continuously between 0 and the auto-reload value in the
TIMx_ARR register (0 to ARR or ARR down to 0 depending on the direction). So you must
configure TIMx_ARR before starting. In the same way, the capture, compare, prescaler,
trigger output features continue to work as normal.
In this mode, the counter is modified automatically following the speed and the direction of
the incremental encoder and its content, therefore, always represents the encoder's
position. The count direction correspond to the rotation direction of the connected sensor.
The table summarizes the possible combinations, assuming TI1 and TI2 don't switch at the
same time.
Table 39.
Active edge
Counting on
TI1 only
Counting on
TI2 only
Counting on
TI1 and TI2
An external incremental encoder can be connected directly to the MCU without external
interface logic. However, comparators are normally be used to convert the encoder's
differential outputs to digital signals. This greatly increases noise immunity. The third
encoder output which indicate the mechanical zero position, may be connected to an
external interrupt input and trigger a counter reset.
The Figure 107
direction control. It also shows how input jitter is compensated where both edges are
Counting direction versus encoder signals
Level on opposite
signal (TI1FP1 for
TI2, TI2FP2 for TI1)
High
Low
High
Low
High
Low
gives an example of counter operation, showing count signal generation and
TI1FP1 signal
Rising Falling
Down Up
Up Down
No Count No Count
No Count No Count
Down Up
Up Down
General purpose timer (TIMx)
TI2FP2 signal
Rising Falling
No Count No Count
No Count No Count
Up
Down
Up
Down
Down
Up
Down
Up
239/501
