Installation

5. I
NSTALLATION
®
5.1 VACON OPTEA Advanced Dual port Ethernet drive support
®
The VACON OPTEA Advanced Dual Port Ethernet option board can be used with the following
®
VACON AC drives. Option board can be used for PROFINET IO with PROFIsafe communication in
slot E, when OPTBL/OPTBM/OPTBN is installed to slot D. If PROFIsafe is not used, then OPTEA can
be installed to slot D too.
AC drive
®
VACON NXP
®
VACON 100 INDUSTRIAL
and 100 X
®
VACON 100 FLOW
®
VACON 100 family support
®
The VACON 100 family AC drives are supported from the OPTEA firmware version V002. The
®
process data in VACON
for later firmware release. Only 16-bit process data is supported. PROFIsafe features are supported
®
only in VACON NXP drives.
EtherNet/IP and Modbus TCP/UDP support
Support for EtherNet/IP, Modbus TCP/UDP and other features which were in OPTE9, were added to
OPTEA firmware V002. Table below shows required minimum AC drive firmware version.
Table 11. Required minimum AC drive firmware versions
VACON
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
Table 10. OPTEA supported AC drives and slots
Slots
D, E
D, E
D, E
100 family AC drives is 32 bit. The 32-bit process data support is planned
AC Drive
®
VACON NXP
®
100 INDUSTRIAL and
100 X
®
VACON 100 FLOW
From AC drive SW From OPTEA SW
version on
NXP00002V196
FW0072V028
FW0159V018
From AC drive SW version on
NXP00002V197
FW0072V028
FW0159V018
vacon • 27
version on
V001
V002
V002
