Installation
5.5 Installation in VACON
Do not add or replace option boards or fieldbus boards on an AC
drive with the power switched on. This may damage the boards.
13006.emf
Open the cover of the drive.
1
The relay outputs and other I/O-terminals may have a dangerous control voltage
present even when the drive is disconnected from mains.
13006.emf
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
®
20 X and 20 CP
MU3 example
vacon • 37
11643_00
5
