Layout and connections

4. L
AYOUT AND CONNECTIONS
®
The VACON Ethernet option boards are connected to the Ethernet bus using the standard RJ45
connectors (1 and 2). The communication between the control board and the AC drive takes place
through a standard VACON
layout and connections.
4.1
Layout and connections
A
B
A
B
Ethernet port
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
®
Interface Board Connector. OPTEA and OPTE9 boards have identical
RN ER BS
1
2
Ethernet connector
Ethernet connector
Figure 1. Option board layout
Table 7. Ethernet ports
1
2
11592_00
C Interface Board connector
Description
Ethernet port 1 (PHY1)
Ethernet port 2 (PHY2)
vacon • 13
C
4
