Vacon optea Installation Manual page 139

EtherNet/IP
Table 105. EtherNet/IP Module Status LED functionality
LEDs State
Steady Red
Flashing Green /
Red
9.1.4.2 Network Status LED
The Network status LED is labeled on the board as "RN". It shows the connectivity status of the
device, that is, if there is a connection to the device, or the IP settings status. The NS LED
functionality is described in the following table.
Table 106. EtherNet/IP Network status LED functionality
LEDs State
Steady Off
Flashing Green No connections
Steady Green
Flashing Red
Steady Red
Flashing Green
/ Red
9.1.4.3 IO Indicator LED
IO Indicator LED is labeled on board as "ER". It shows the status of IO connection. This functionality
was added in OPTE9 firmware V009 and in OPTEA firmware V002. The LED functionality is described
in the following table.
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
Summary
If the device has detected a non-recoverable
Major fault major fault, the module status indicator is
While the device is performing its power up
Self-test
Summary
The device is powered off, or is powered on
Not powered, but with no IP address configured (Interface
no IP address Configuration attribute of the TCP/IP Inter-
An IP address is configured, but no CIP con-
nections are established, and an Exclusive
Owner connection has not timed out.
At least one CIP connection (any transport
Connected class) is established, and an Exclusive
Owner connection) has not timed out.
An Exclusive Owner connection for which
this device is the target has timed out. The
LED returns to steady green only when all
Connection
timed out Exclusive Owner connections are
timeout
re-established. Timeout of connections
other than Exclusive Owner connections will
not cause the indicator to flash red.
The device has detected that its IP address
Duplicate IP is already in use by another device in the
While the device is performing its power up
Self-test
vacon • 139
Requirement
steady red.
testing.
Requirement
face Object).
network.
testing
9
