Please read these warnings carefully: The components of the power unit of the frequency converter are live when Vacon 10 is connected to mains potential. Com- ing into contact with this voltage is extremely dangerous and may cause death or severe injury.
• installation vacon 2. INSTALLATION 2.1 Mechanical installation There are two possible ways to mount Vacon 10 in the wall; either screw or DIN-rail mounting. MI2-3 =M 5 =M 4 Figure 1: Screw mounting (left) and DIN-rail mounting (right) NOTE! See the mounting dimensions on the back of the drive.
2.2.2 Control cabling Figure 5: Open the cover Control cable tightening torque: 0.4 Nm Strip the plastic cable coating for 360°earthing Figure 6: Install the control cables. See next page! 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
250Vac/2A or 250Vdc/ 25 RO 22 opened) = FAULT 0,4A Table 1: Vacon 10 General purpose application default I/O configuration and connections for API RS-485 version Vacon 10 RS-485 I/O terminals: 25 24 Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
Page 7
4. NAVIGATION & STARTUP 4.1 The status LEDs of Vacon 10 RS-485 There are three status LED lights on the front panel of Vacon 10 RS-485. The LEDs indicate the status of the drive, provide the user with information on faults and help the user to select the control place or fieldbus address.
8. Run no-load tests without motor being connected to the process 9. Connect the motor to the process and perform test run once again 10. Vacon 10 rs-485 is now ready for use Table 1: Commissioning steps Tel. +358 (0)201 2121 • Fax +358 (0)201 212205...
4.3 Selection of control place or fieldbus address In Vacon 10 RS-485 the user can select the control place and Modbus slave address without connecting the drive to PC. The procedures are described below. 4.3.1 Selection of control place...
Page 10
Address 5 Confirm the desired address with START button: Vacon 10 will return to READY state and fieldbus is now the control place and frequency reference source of the drive. Via PC tools or fieldbus the address can be selected between 1 and 255. (NOTE: if no button is pressed in 30 seconds, the drive will always return to READY state) Tel.
In percent of the maximum M1.19 PI error value error value In percent of the maximum out- M1.20 PI Output put value Table 1: Vacon 10 API RS-485 monitoring values (General purpose application) 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
P3.4 Preset speed 0 0,00 P3.2 5,00 Activated by digital inputs P3.5 Preset speed 1 0,00 P3.2 10,00 Activated by digital inputs P4.2 Acceleration time 3000 P4.3 Deceleration time 3000 P10.4 Automatic restart 0 = Not used 1 = Used...
(MENU PAR -> S3) S3.1 MWh counter S3.2 Power on days S3.3 Power on hours User settings (MENU PAR -> S4) S4.2 Restore factory defaults 1= Restores factory defaults Table 3: System menu parameters 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
6. FAULT TRACING In Vacon 10 RS-485, the red FAULT LED gives information on the active faults to the user. The red LED blinks in certain sequences according to the fault type. The se- quences are presented below:...
