Commissioning
Name
Speed/Duplex
Sub menu: EtherNet/IP
EIP Product Code
EIP Output Instance
EIP Input Instance
Sub menu: PROFINET IO
Name Of Station
IOC NOS
System Redundancy
Sub menu: SNTP
SNTP status
Server IP P1
Server IP P2
Server IP P3
Server IP P4
Last Update time
6.1.3

Communication protocol

The OPTEA and OPTE9 option boards come with several fieldbus protocols. The user can select the
one used in their network from the list. Only one protocol can be active at a time. Since OPTEA
firmware version V002 and OPTE9 firmware version V008, you can also select "none" from the list.
With this selection, no fieldbus protocol is active in option board. This also means that the option
board does not generate fieldbus timeout fault if the Ethernet cable is not connected. The PC tool
connections and SNTP time updates are possible in this mode.
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
Range
Undefined (1),
10 HD (2),
10 FD (3),
100 HD (4),
100 FD (5)
-
0 - 161
0 - 167
-
-
None (1),
Fault (2),
Backup (3),
Primary only (4),
Redundant (5)
Stopped (1),
Internal error (2),
Invalid configuration (3),
Finding server (4),
Failed (5),
Synchronized Time (6),
Lost connection (7)
0...255
0...255
0...255
0...255
0...65535
Description
Shows current Ethernet link speed and duplex
value.
Currently used EtherNet/IP Product Code
Currently used output instance. Zero is shown
if EtherNet/IP is not the active protocol
Currently used input instance. Zero is shown if
EtherNet/IP is not the active protocol|
Name of station value truncated to be shown in
panel. It shows partial Name Of Station value.
This value is visible only in NX family drives.
Name Of Station of the IO controller, i.e. the
PLC connected to this board
State of system redundancy if active. Visible
with OPTEA board.
Shows current SNTP status. Value is stopped
when SNTP is not enabled.
Currently active SNTP server address part 1
Currently active SNTP server address part 2
Currently active SNTP server address part 3
Currently active SNTP server address part 4
Seconds since time update was received from
network. Value shows zero until first update
since drive startup.
