6.1.13

Media Redundancy

This value shows the current state of the active media redundancy protocol. DLR can be active only
when EtherNet/IP is the active protocol and MRP when PROFINET has been selected.
The values are mapped in the following way:
• 0 = No ring protocol
• 0# = Ring protocol initializing
• 1# = Ring protocol status ok
• 2# = Ring protocol failure
• #1-#3 = MPR
• #4-#6 = DLR
The value definitions and how they map to media redundancy specification states (in MRP MRC state
machine and in DLR announce based node state machine) are defined in table below.
Value Name
0 None
1 MRP (Ring) Init
11 MRP (Ring) Ok
21 MRP (Ring) Fault
MRP (Ring)
22
Stopped
4 DLR (Ring) Init
14 DLR (Ring) Ok
24 DLR (Ring) Fault
DLR (Ring)
25
Stopped
6.1.14

SNTP settings

The SNTP settings are used to enable Simple Network Time Protocol for updating date and time to
drive from network.
6
Table 22. Values for MPR
Description
• No active ring protocol
• Protocol is initializing
• Ring ports are ok
• MRP_Test frames are received from both ports
• One of the ring ports have a failure
• Transitioning from one state to another
• MRP_Test frames are not received from both
ports
• Both ring ports have a failure
• Can be active briefly during a transition
between states
• No announce based DLR frames have been
received after starting up DLR protocol
• Ring is closed and without fault
• Ring is open because of a ring failure
• DLR protocol has transitioned back to
IDLE_STATE
• Either both ports have no link or no Announce
frames received within timeout time
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
Commissioning
Standard state
-
Power up
PT_IDLE
PT_IDLE,
DE_IDLE, DE, PT
AC_STAT1
IDLE_STATE
NORMAL_STATE
FAULT_STATE
IDLE_STATE
