Telegram Building Blocks - Vacon optea Installation Manual

vacon • 104
Bit
12
13
14
15
Table below describes Status Word for the OPTCP Vendor PPO telegrams.
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
*Comes straight from the drive
** Bits of the State Machine
8.3.3

Telegram building blocks

8.3.3.1 PROFIdrive Control Word 1 (STW1)
The following table lists the assignments of bits in the control word 1.
NOTE! OPTEA in OPTCx mode will do same FBDIN bit mapping as OPTCP option board does.
8
Description
Fieldbus DIN2=OFF
Fieldbus DIN3=OFF
Fieldbus DIN4=OFF
Fieldbus DIN5=OFF
Description
Value = 0
Not Ready (initial)
Not Ready
DISABLE
NO FAULT
STOP 2
STOP 3
START ENABLE
No Warning
Reference ≠ Actual value
Fieldbus control OFF
Not used
Not used
FC stopped
FC not ready
Not used
Not used
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
PROFINET IO
Fieldbus DIN2=ON
Fieldbus DIN3=ON
Fieldbus DIN4=ON
Fieldbus DIN5=ON
Value = 1
READY 1 **
READY 2 **
ENABLE **
FAULT ACTIVE **
NO STOP 2**
NO STOP 3 **
START DISABLE **
Warning *
Reference = Actual value *
Fielbus control ON *
Not used
Not used
Running
FC ready *
Not used
Not used
