Commissioning
Table 19. Emulation mode when installed to VACON
Value
1
2
When installed to VACON
series Ethernet option boards and with "VACON100" mode the Vacon100 internal implementations.
Table 20. Emulation mode when installed to VACON
Value
1
2
3
It is required to restart the AC drive after you have changed the emulation mode.
See Chapter 6.5 "OPTCx emulation mode" for more details.
6.1.11

MAC Address

This value shows the option board's device MAC address. The format differs between used VACON
®
AC drive. In VACON 100 family AC drives, the format is 00:11:22:33:44:55, and in VACON
NXP, the value is 001122334455. This value is not visible in VACON
®
Example for VACON 100 family AC drive: 00:21:99:1a:00:24
®
Example for VACON NXS/NXP: 0021991a0024
6.1.12

Modbus Unit Identifier

This value is used to select Modbus unit identifier / slave address. When using Modbus TCP the
value 255 must be used, and this field is ignored as the IP address is used to access the correct
device. When using Modbus UDP the values and their significance is explained in table below. Values
from 1 to 247 and 255 can be set.
Table 21. Modbus Unit Identifier field description when using Modbus UDP
# Unit identifier
0 Broadcast
1...247 Slave address
255 Non-significant
The value 0 can be used to control several devices with a broadcast message, e.g. to command all
devices to stop at the same time. This feature will also work if all devices have the unit identifier
value 255.
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
Emulation mode
Normal Normal operation
Emulating OPTC-series ethernet boards as
OPTCx
accurately as possible
®
100 family drive and "NX" mode is selected, OPTEA will also emulate C-
Emulation mode
Normal Normal operation
Emulating OPTC-series ethernet boards in
NX
VACON
V100
Emulating VACON
Broadcast address, messages are accepted by all devices
Messages with this unit identifier and broadcast (0) are accepted
Messages with all unit identifiers are accepted (setting is ignored)
®
NXP drive
Description
®
100 family drive
Description
®
100 family type drive
®
100 family drive
®
20 family AC drives.
Description
vacon • 65
®
®
NXS and
6
