vacon • 60
6.1.2

Option board monitoring values

The monitor menu shows the currently active IP settings. For example, these values will show '0'
when a DHCP server is trying to get an IP address. After the address is received, these values are
updated.
Name
Fieldbus protocol status
Communication status
Drive control word
Drive status word
Protocol control word
Protocol status word
MAC Address
Media Redundancy
Sub menu: IP Settings
IP Part 1
IP Part 2
IP Part 3
IP Part 2
Subnet mask P1
Subnet mask P2
Subnet mask P3
Subnet mask P4
Default GW P1
Default GW P2
Default GW P1
Default GW P4
6
Table 16. Option board monitoring values
Range
Initializing (1),
Stopped (2),
Operational (3),
Faulted (4),
Failing (5)
0.0...64.999
-
-
-
-
-
None (0)
MRP Ring Init (1)
MRP Ring Ok (11)
MRP Ring Fault (21)
DLR Ring Init (4)
DLR Ring Ok (14)
DLR Ring Fault (24)
DLR Ring Stopped (25)
1...223
0...255
0...255
0...255
0...255
0...255
0...255
0...255
0...223
0...255
0...255
0...255
Local contacts: https://www.danfoss.com/en/contact-us/contacts-list/
Description
When device has started, it stays in "Initializ-
ing" status until the connection is opened to
the device. At that point, the status changes to
"operational".
If the connection is closed or lost, the status
changes to "Failing" until communication time-
out time has elapsed. Then the status changes
to "Faulted".
0-64 Number of messages with errors
0-999 Number of messages without communi-
cation errors
Control word in drive format
Status word in drive format
Control word in protocol format
Status word in protocol format
Used device MAC address. Available in
®
VACON NXP, NXS and VACON
drives.
State of active media redundancy protocol
Current IP Address Part 1
Current IP Address Part 2
Current IP Address Part 3
Current IP Address Part 4
Current Subnet Mask Part 1
Current Subnet Mask Part 2
Current Subnet Mask Part 3
Current Subnet Mask Part 4
Current Default Gateway Part 1
Current Default Gateway Part 2
Current Default Gateway Part 3
Current Default Gateway Part 4
Commissioning
®
