Configuring an E1
Channel
Configuring a T1
Channel
n
E1 configuration is supported on the CPOS (E) interface module while T1
configuration is supported on the T1 CPOS (T) interface module.
Follow these steps to configure an E1 channel:
To do...
Enter system view
Enter CPOS interface view
Set the E1 framing format
Set the clock mode for E1
Set the loopback mode for E1
Configure the Configure E1
E1 operating to operate in
mode (in unframed
either mode
approach)
Configure E1
to operate in
channelized
mode and set
timeslot
bundling
n
E1 configuration is supported on the CPOS (E) interface module.
Follow these steps to configure a T1 channel:
To do...
Enter system view
Enter CPOS interface view
Set the T1 framing format
Set the clock mode for T1
Set the loopback mode for T1

Configuring an E1 Channel

Use the command...
system-view
controller cpos
cpos-number
e1 e1-number set
frame-format { crc4 |
no-crc4 }
E1 e1-number set clock
{ master | slave }
e1 e1-number set loopback
{ local | payload | remote }
e1 e1-number unframed
undo e1 e1-number
unframed
e1 e1-number channel-set
set-number timeslot-list
range
Use the command...
system-view
controller cpos
cpos-number
t1 t1-number set
frame-format { esf | sf }
t1 t1-number set clock
{ master | slave }
t1 t1-number set loopback
{ local | payload | remote }
545
Remarks
--
Required
Optional
The default is no-CRC4.
Optional
The default is slave.
Optional
Disabled by default
Required
The default is channelized
mode.
Optional
The default is channelized
mode
Required
Timeslot bundling is disabled
by default.
Remarks
--
Required
Optional
The default is ESF.
Optional
The default is slave.
Optional
Disabled by default
