218 C 7: DLS
HAPTER W
Configuring DLSw in
an SDLC Environment

Configuring DLSw

C
ONFIGURATION
To do...
Create a MAC-based Layer
2 ACL
Return to system view
Apply a MAC-based ACL
on inbound and/or
outbound traffic
For details about creating a Layer 2 ACL, refer to ACL Configuration in the Security
Volume.
Follow these steps to configure DLSw:
To do...
Enter system view
Enable DLSw
Create a DLSw peer
Configure an SDLC interface
Enable DLSw forwarding on
an SDLC interface
Configure SDLC roles
Configure an SDLC address
for a secondary station
Configure an SDLC peer
Configure an SDLC XID
Configure an SDLC virtual
MAC address
Configure the properties of a
synchronous serial interface
Configure optional SDLC
parameters
Use the command...
acl number acl-number
[ match-order { auto | config } ]
rule [ rule-id ] { deny | permit }
[ fragment | logging | source
{ sour-addr sour-wildcard | any } |
time-range time-name |
vpn-instance
vpn-instance-name ] *
quit
dlsw ethernet-frame-filter
acl-number inbound
dlsw ethernet-frame-filter
acl-number outbound
Use the command...
system-view
dlsw enable
Refer to "Creating DLSw Peers" on page
214
Refer to "Configuring an SDLC Interface"
on page 219
Refer to "Enabling DLSw Forwarding on
an SDLC Interface" on page 219
Refer to "Configuring SDLC Roles" on
page 219
Refer to "Configuring an SDLC Address
for a Secondary Station" on page 220
Refer to "Configuring an SDLC Peer" on
page 221
Refer to "Configuring an SDLC XID" on
page 221
Refer to "Configuring an SDLC Virtual
MAC Address" on page 222
Refer to "Configuring the Properties of
an Synchronous Serial Interface" on page
222
Refer to "Configuring the Properties of
an Synchronous Serial Interface" on page
222
Remarks
Required
No Layer 2 ACL is configured
by default.
-
Required
By default, no ACL is applied.
ACLs for inbound and
outbound traffic can be
configured at the same time
Remarks
-
Optional
Enabled by default
Required
Required
Required
Required
Required
Required
Optional (required
for PU2.0 devices)
Optional
Optional
Optional
