266 C 11: MP FR
HAPTER O
MPoFR Configuration
Example
To do...
Configure PPPoFR on two
or more virtual templates,
and bind to virtual
template interface
configured with PPP MP
Quit to system view
c
CAUTION:
To ensure packet transmission quality over virtual-template (VT) interfaces, you
■
can configure queue-independent QoS features on VT interface and
queue-dependent QoS features on FR interface. For detailed information, refer
to "QoS Overview" on page
As for the next hop and the outbound interface, only the former is required
■
when you configure a static route on a virtual-template interface. If you want
to specify the outbound interface as well, make sure the physical interface
bound to the virtual-template interface is valid.
Refer to "PPP and MP Configuration" on page 363
■
MP-related configuration.
Network requirements
ATM backbone network uses FR network as access network to support
transmission of multiple services. A single virtual circuit of FR link can transport
multiple kinds of service data.
As shown in the network diagram, the bandwidth of Router A Serial2/0 is 64
kbps. PC1 sends data service stream 1 to PC3, PC2 sends data service stream 2 to
PC4 and there is also a voice service stream.
The bandwidth of Router B Serial2/0 is 64 kbps. PC3 sends data service stream 3
to PC1, PC4 sends data service stream 4 to PC2, and there is also a voice service
stream.
Use the command...
Create virtual interface
template interface virtual-template
and enter the virtual interface-number
template interface
view
Configure MP on ppp mp
virtual template virtual-template
interface interface-number-m
p
Quit to system view quit
Enter the interface
corresponding frame interface-type
relay interface interface-number
Configure frame relay link-protocol fr
as the link protocol
Configure a frame fr dlci dlci-number
relay DLCI
Map frame relay DLCI fr map ppp
to PPP dlci-number
interface
virtual-template
interface-number
quit
1623.
Remarks
-
Required
-
-
Required
Required
(optional for DTE
side)
Required
-
for information about
