750 C 51: T
HAPTER ERMINAL
n
A C
CCESS ONFIGURATION
To do...
Exit terminal template view quit
Enter interface view
Configure the
asynchronous serial
interface to operate in the
flow mode
Apply the template to the
interface
Exit interface view
Enter TTY user interface
view
Enable software flow
control of the data on the
current user interface
For details about the async mode flow command, refer to the async mode
■
command in "WAN Interface Configuration" on page
After a template is applied on an interface, you need to set the flow control
■
mode of the user interface corresponding to the interface to software flow
control. You can use the display user-interface command to display the
associations between interfaces and user interfaces.
For details about the user-interface command, refer to the user-interface
■
command in "User Interface Configuration" on page
For details about the flow-control software command, refer to the
■
flow-control command in
Follow these steps to perform advanced TTY initiator configuration:
To do...
Enter system view
Configure the global
source IP address of TCP
connection
Bind the MAC address of
the interface for service
connection authentication
Bind the character string
for service connection
authentication
Enter terminal template
view
Configure the automatic
link teardown time
Use the command...
interface interface-type
interface-number
async mode flow
rta terminal template-name
terminal-number
quit
user-interface { first-num1
[ last-num1 ] | tty first-num2
[ last-num2 ] }
flow-control software
"User Interface Configuration" on page
Use the command...
system-view
rta source-ip ip-address
rta bind mac-address
interface interface-type
interface-number
rta bind string string
rta template
template-name
auto-close time
Remarks
-
-
Required
By default, an asynchronous
serial interface operates in the
protocol mode and an AUX
interface the flow mode.
Required
-
-
Required
By default, the flow control
mode is none; that is, no flow
control is implemented.
99.
2155.
2155.
Remarks
-
Optional
Not configured by default
Optional
Not configured by default
Optional
Not configured by default
-
Optional
0 seconds by default; that is, no
automatic link teardown is
performed.
