# Configure the users in the domain to use the local authentication scheme.
[RouterC] domain system
[RouterC-isp-system] authentication ppp local
Network requirements
As showed in the figure below, Router A and Router B are connected together
through serial ports, Serial 2/0 to Serial 2/0 and Serial 2/1 to Serial 2/1 respectively.
Three binding modes that are demonstrated are directly Virtual-Template binding
mode, authentication binding mode and MP-group interface binding mode.
Network diagram
Figure 98 Network diagram for MP binding mode configuration
S2 /0 S2/0
MP
S2 /1 S2/1
Router A Router B
Configuration procedure
1 Directly assign physical interfaces to a virtual template interface
Configure Router A:
# Configure the username and password of Router B
<RouterA> system-view
[RouterA] local-user rtb
[RouterA-luser-rtb] password simple rtb
[RouterA-luser-rtb] service-type ppp
[RouterA-luser-rtb] quit
# Create a virtual template interface and assign an IP address to it.
[RouterA] interface virtual-template 1
[RouterA-Virtual-Template1] ip address 8.1.1.1 24
[RouterA-Virtual-Template1] ppp mp binding authentication
# Configure Serial 2/1.
[RouterA-Virtual-Template1] interface serial 2/1
[RouterA-Serial2/1] link-protocol ppp
[RouterA-Serial2/1] ppp authentication-mode pap domain system
[RouterA-Serial2/1] ppp pap local-user rta password simple rta
[RouterA-Serial2/1] ppp mp virtual-template 1
[RouterA-Serial2/1] shutdown
[RouterA-Serial2/1] undo shutdown
[RouterA-Serial2/1] quit
# Configure Serial 2/0.
[RouterA] interface serial2/0
[RouterA-Serial2/0] link-protocol ppp
[RouterA-Serial2/0] ppp authentication-mode pap domain system
[RouterA-Serial2/0] ppp pap local-user rta password simple rta
