Configuring CT1/PRI
Interface in CT1 Mode
Configuring an CT1/PRI
Interface operating as a
PRI interface
When it is working as a PRI interface, timeslot 24 is used as a D channel for
■
signaling transmission. Therefore, only a group of timeslots except timeslot 24
can be chosen as the B channel. This timeslot group is bundled together with
timeslot 24 to form a PRI set. This PRI set will work as an interface logically
equivalent to an ISDN PRI interface where you can configure PPP at the data
link layer, IP or IPX at the network, DCC, and other configurations.
The timeslots on a CT1/PRI interface can be bundled into either channel sets or a
PRI set at a time.
Follow these steps to configure a CT1/PRI interface in CT1 mode:
To do...
Enter system view
Enter CT1/PRI interface view
Bundle timeslots on the
interface into channel sets
Configure other interface
parameters
For each channel set, the system automatically creates a serial interface numbered
serial number:set-number. This interface is logically equivalent to a synchronous
serial interface where you can make other configurations about:
Data link protocol such as
■
Configuration" on page
"IP Addressing Configuration" on page 623
■
"Backup Center Configuration" on page 1961
■
primary or secondary interface for backup
"NAT-PT Configuration" on page 679
■
on page 1794 if a firewall is to be set up
Follow these steps to configure a CT1/PI interface operating as a PRI mode:
To do...
Enter system view
Enter CT1/PRI interface view
Bundle timeslots on the
interface into a PRI set
Configure other interface
parameters
Use the command...
system-view
controller t1 number
channel-set set-number
timeslot-list list [ speed
{ 56k | 64k } ]
See "Configuring Other
CT1/PRI Interface Parameters"
on page 112.
"PPP and MP Configuration" on page
2385, "X.25 and LAPB Configuration" on page 283
if the interface is used as a
and "Configuring a Packet Filter Firewall"
Use the command...
system-view
controller t1 number
pri-set [ timeslot-list list ]
See "Configuring Other
CT1/PRI Interface Parameters"
on page 112.
CT1/PRI Interface 111
Remarks
--
Required
Required
Up to 24 channel sets can be
bundled.
The default timeslot speed is
64 kbps.
Optional
363, "VoFR
Remarks
--
Required
Required
Only one PRI set can be
created at a time.
Optional
