Configuring Frame Relay Switching - 3Com MSR 50 Series Configuration Manual

240 C 8: F
HAPTER RAME
Configuring Frame Relay
Switching
R C
ELAY ONFIGURATION
"Configuration procedure" on page 239
■
Overview
When the frame relay interface type is DCE or NNI, the interface (either main
interface or subinterface) must be manually configured with virtual circuits. When
the frame relay interface type is DTE, for the main interface, the system will
determine the virtual circuit automatically according to the peer device, and the
main interface can also be manually configured with virtual circuits; for
subinterface, it is required to manually configure virtual circuits.
A virtual circuit number is unique on a physical interface.
Configuration procedure
Follow these steps to configure frame relay local virtual circuit
To do...
Enter system view
Enter interface view
Configure virtual circuit on
interface
This section covers these topics:
"Overview" on page 235
■
"Configuration procedure" on page 239
■
Overview
A device with frame relay switching function enabled can act as a frame relay
switch. In this scenario, the frame relay interface should be NNI or DCE and it is
required to perform corresponding configuration on the two or more interfaces
used for frame relay switching before the frame relay switching function can work.
To configure frame relay switching, you can configure static routes for frame relay
switching in interface view or configure PVC for frame relay switching in system
view.
Configuration procedure
Follow these steps to configure frame relay switching:
To do...
Enter system view
Enable frame relay switching
Enter interface view
Use the command...
system-view
interface interface-type
interface-number
fr dlci dlci-number
Use the command...
system-view
fr switching
interface interface-type
interface-number
Remarks
-
-
Required
There is no virtual circuit on
interface by default.
Remarks
-
Required
-
