IP Routing and
Routing Table

Routing

Routing Table
IP R
OUTING
Go to these sections for information you are interested in:
"IP Routing and Routing Table" on page 815
■
"Routing Protocol Overview" on page 817
■
"Displaying and Maintaining a Routing Table" on page 821
■
Routing in the Internet is achieved through routers. Upon receiving a packet, a
router finds an optimal route based on the destination address and forwards the
packet to the next router in the path until the packet reaches the last router, which
forwards the packet to the intended destination host.
Routing table
Routing tables play a key role in routing. Each router maintains a routing table,
and each entry in the table specifies which physical interface a packet destined for
a certain destination should go out to reach the next hop (the next router) or the
directly connected destination.
Routes in a routing table can be divided into three categories by origin:
Direct routes: Routes discovered by data link protocols, also known as interface
■
routes.
Static routes: Routes that are manually configured.
■
Dynamic routes: Routes that are discovered dynamically by routing protocols.
■
Contents of a routing table
A routing table includes the following key items:
Destination address: Destination IP address or destination network.
■
Network mask: Specifies, in company with the destination address, the address
■
of the destination network. A logical AND operation between the destination
address and the network mask yields the address of the destination network.
For example, if the destination address is 129.102.8.10 and the mask
255.255.0.0, the address of the destination network is 129.102.0.0. A
network mask is made of a certain number of consecutive 1s. It can be
expressed in dotted decimal format or by the number of the 1s.
Outbound interface: Specifies the interface through which the IP packets are to
■
be forwarded.
