Introduction to Voice
VLAN
V VLAN C
OICE
When configuring Voice VLAN, go to these sections for information you are
interested in:
"Introduction to Voice VLAN" on page 497
■
"Configuring the Voice VLAN" on page 500
■
"Displaying and Maintaining Voice VLAN" on page 501
■
"Voice VLAN Configuration Examples" on page 502
■
n
Voice VLAN automatic mode and secure mode are not supported on MSR 20
■
series routers.
Voice VLAN automatic mode and secure mode are not supported on SIC-4FSW
■
and DSIC-9FSW modules.
Voice VLAN automatic mode and secure mode are supported on 16FSW and
■
24FSW modules.
Voice VLANs are configured specially for voice traffic. By adding the ports that
connect voice devices to voice VLANs, you can configure quality of service (QOS
for short) attributes for the voice traffic, increasing transmission priority and
ensuring voice quality. A device determines whether a received packet is a voice
packet by checking its source MAC address. Packets containing source MAC
addresses that comply with the voice device Organizationally Unique Identifier
(OUI for short) addresses are regarded as voice traffic, and are forwarded in the
voice VLANs.
You can configure the OUI addresses in advance or use the default OUI addresses
as listed in Table
Table 17 The default OUI addresses of devices
Number
1
2
3
4
5
6
7
ONFIGURATION
17.
OUI address
0001-e300-0000
0003-6b00-0000
0004-0d00-0000
00d0-1e00-0000
0060-b900-0000
00e0-7500-0000
00e0-bb00-0000
Vendors
Siemens phone
Cisco phone
Avaya phone
Pingtel phone
Philips/NEC phone
Polycom phone
3Com phone
