Bandwidth-Based Load Sharing Configuration Example - 3Com MSR 50 Series Configuration Manual

822 C 55: IP R
HAPTER OUTING
Configuration
Example
Bandwidth-based Load
Sharing Configuration
Example
O
VERVIEW
Network requirements
On Router A, there are three equal-cost routes to the destination network
10.2.1.0 /24, as shown below:
<Sysname> display fib
Destination/Mask
10.2.1.0/24
10.2.1.0/24
10.2.1.0/24
Use the display loadsharing ip address command to display bandwidths on
interfaces.
<Sysname> display load-sharing ip address 10.2.1.0 24
There are/is totally 3 route entry(s) to the same destination network.
Nexthop Packet(s)
10.1.1.2 763851
10.1.2.2 1193501
10.1.3.2 15914
# The display shows that packets are load-shared according to their default
bandwidths.
Specify bandwidths fpr the three interfaces on Router A and observe the load
sharing.
Network diagram
Figure 230 Network diagram for bandwidth-based non-balanced load sharing
Router A
Eth1 /0
ATM 1/0
Serial 2/0
Configuration procedure
1 Configure Router A
# Configure load sharing bandwidths for the three interfaces.
<Sysname> system-view
[Sysname] interface ethernet 0/0
[Sysname-Ethernet0/0] loadbandwidth 200
[Sysname-Ethernet0/0] quit
[Sysname] interface Atm 1/0
[Sysname-Atm 1/0] loadbandwidth 100
[Sysname-Atm 1/0] quit
[Sysname] interface serial 2/0
[Sysname-serial 2/0] loadbandwidth 300
[Sysname-serial 2/0] quit
Nexthop Flag TimeStamp
10.1.1.2 GSU
10.1.2.2 GSU
10.1.3.2 GSU
Bandwidth[KB] Flow(s)
100000
155000
2048
IP network
Interface
t[0] Ethernet0/0
t[0] Atm1/0
t[0] Serial2/0
Interface
0 Ethernet0/0
0 Atm1/0
0 Serial2/0
Router B
Serial 2 /0
