396 C 20: PPP E C
HAPTER O

Configuration Procedure

n
Resetting/Deleting a
PPPoE Session
ONFIGURATION
For more information on the configuration of PPPoE session on virtual Ethernet
interface, refer to the relevant part of PPPoEoA configuration in
Interface Configuration" on page 71
Follow these steps to configure PPPoE client:
To do...
Enter system view
Configure dialer rule
Create a dialer interface
Create a dialer user
Configure IP address of the
interface
Configure dialer bundle of
the interface
Configure dialer group of the
interface
Exit to system view
Enter Ethernet interface view
Create a PPPoE session and
specify the dialer bundle for
the session
Depending on your requirement, you may need to configure PPP authentication
etc on dialer interface. For detailed description on how to configure a dialer
interface, refer to
Introduction to resetting/deleting a PPPoE session
The device supports two kinds of PPPoE connection mode: permanent on-line
mode and packet triggering mode.
Permanent on-line mode: When the physical line is up, the device will quickly
■
initiate PPPoE call to create a PPPoE session. The PPPoE session will always exist
unless the user deletes it.
Packet triggering mode: When the physical line is up, the device will not
■
immediately initiate PPPoE call. Only when there is data transmission
requirement will the router initiate PPPoE call to create a PPPoE session. If the
free time of a PPPoE link exceeds the value set by user, the router will
automatically terminate the PPPoE session.

Resetting/deleting a PPPoE session

Follow these steps to reset/delete a PPPoE session:
in Access Manual.
Use the command...
system-view
dialer-rule dialer-group
{ protocol-name { permit | deny } | acl
acl-number }
interface dialer number
dialer user username
ip address { address mask |
ppp-negotiate }
dialer bundle bundle-number
dialer-group group-number
quit
interface ethernet interface-number -
pppoe-client dial-bundle-number
number [ no-hostuniq ]
[ idle-timeout seconds
[ queue-length packets ] ]
"DCC Configuration" on page
"ATM and DSL
Remarks
-
Required
Required
Required
Required
Required
Required
-
Required
153.
