Incoming Call; Configuring To Send Calling Number During An Outgoing Call - 3Com MSR 50 Series Configuration Manual

Setting the Called
Number or Sub-Address
to Be Checked During a
Digital Incoming Call
Configuring to Send
Calling Number During
an Outgoing Call
To do...
Set the SPID Set the SPID value of B1
types on the on the BRI interface
BRI interface adopting NI protocol.
adopting NI
Set the SPID value of B2
protocol as
on the BRI interface
NIT, static and
adopting NI protocol.
dynamic.
When Enable the SPID
configuring, negotiation on the BRI
only one of interface adopting NI
them can be protocol.
available once.
On the BRI interface
adopting NI protocol,
set the processing
mode of SPID to NIT,
i.e., non-initializing
terminal mode.
Set the service type supported by SPID
Set the time-interval of timer TSPID on
the BRI interface adopting NI protocol.
Set the number of times of resending
message on the BRI interface adopting NI
protocol.
If a called number or subaddress is specified, the system will deny an incoming
digital call if the calling party sends a wrong called number or subaddress or does
not send at all.
Follow these steps to configure the called number or sub-address to be checked
during a digital incoming call:
To do...
Enter system view
Enter specified interface
view
Set the called number or
sub-address to be checked
during a digital incoming
call
The purpose for setting this command is to reduce cost in some networks that
charge the calling side by providing advantageous accounting numbers for users.
Follow these steps to configure to send calling number during an outgoing call:
Use the command...
isdn spid1 spid [ ldn ]
isdn spid2 spid [ ldn ]
isdn spid auto_trigger Optional
isdn spid nit
isdn spid service
[ audio | data | speech ]
isdn spid timer seconds Optional
isdn spid resend times
Use the command...
system-view
interface interface-type
interface-number
isdn check-called-number
called-party-number
[ :subaddress ]
Configuring ISDN
Remarks
Required
SPID is obtained via
dynamic negotiation by
default.
A BRI interface does not
originate a SPID
negotiation request
unless triggered by a call
by default.
NIT does not apply on
BRI interfaces by default.
SPID needs to support
speech and data service
simultaneously.
The time-interval of
timer TSPID is 30
seconds by default.
Optional
Once by default.
Remarks
-
-
Optional
No called number or sub-address
is configured by default. When
configuring this command, the
called number and subaddress
are separated with string "space:
space".
429
