Polycom RealPresence 4000 Administrator's Manual page 679

Table 21-15
Name
ServiceH323
ServiceSIP
ServiceISDN
RsrcAllocMode
McuSystemStatus
FanStatus
PowerSupplyStatus
IntegratedBoardsStatus
UltraSecureMode
ChassisTemp
NumPortsUsed
NewCallsPerMinute
ScsfNewCallsPerMinute
FldNewCallsPerMinute
PctScsflNewCalls
CallsEndedScsflPerMin
CallsEndedFailedPerMin
CallsEndedScsfl
CallsEndedFailed
NumActvCnfrncs
Polycom, Inc.
Unified MIB SNMP Fields (Continued)
Type
Integer
Integer
Integer
Fixed/
Flexible
Integer
Boolean
Boolean
Boolean
Boolean
Integer
Integer
Integer
Integer
Integer
Integer
Integer
Integer
Integer
Integer
Integer
Chapter 21-RMX Administration and Utilities
Description
Indicates the status of H.323 capabilities:
1 - The service is enabled and operational.
2 - The service is enabled but is not operational.
3 - The service is disabled.
Indicates the status of SIP capabilities:
1 - The service is enabled and operational.
2 - The service is enabled but is not operational.
3 - The service is disabled.
Indicates the status of SIP capabilities:
1 - The service is enabled and operational.
2 - The service is enabled but is not operational.
3 - The service is disabled.
The resource allocation method which determines
how the system resources are allocated to the
connecting endpoints.
System State.
Status of the hardware fan.
Status of the power supply.
Status of the integrated boards.
Indicates whether the RMX is operating in Ultra
Secure Mode.
The temperature of the chasis.
Number of ports currently in use.
New calls in the last minute.
Successful new calls in the last minute.
Failed new calls in the last minute.
Percentage of new calls in the last minute which
were successful.
Number of calls in the last minute which ended with
a success code.
Number of calls in the last minute which ended with
a failure code.
Number of calls in the last minute which ended with
a success code.
Number of calls in the last minute which ended with
a failure code.
Number of active conferences.
21-33
