Configuring and Modifying Precedence Domains and DSCP Values

The Precedence Domains and DSCP values for each Precedence Domain can be configured and
modified per MCU.
To configure Precedence Settings:
1
2
23-42
On the RMX menu, click Setup > Precedence Settings
The Precedence Settings dialog box is displayed.
Optional: Modify the values if required.
Table 23-11 Precedence Settings - Domains, Levels and DSCP Values
Field
Use Precedence
Precedence Domain
Domain Name
Signaling DSCP
Select or clear the check box to enable or disable Precedence.
Default: Cleared (Precedence disabled)
Select the Precedence Domain to be modified, 1 or 2, from the drop-
down menu.
Possible Values: 1 / 2
Enter the required Domain Name.
Modify the DSCP value of the Signaling DSCP. A single Signaling
Proxy is used for all Precedence Levels.
Default: 40
Range: 0 - 63
Description
