MPMx Card Properties

To view the MPMx Properties:
1
Right clicking on any RMX MPMx card will display the cards Properties.
2
Figure
The MPMx card has 7 temperature sensors numbered: 11-17, for example, when sensor 13
reaches 70
The Sensor numbering and Temperature listings may vary on RMX systems depending on
card's Hardware Version and Software Version number. The RMX Manager and RealPresence
Collaboration Server Client version can also affect the UI or change the look & feel.
The "Upper Major" event results in an alarm being triggered. Perform an overall system
check. If a temperature sensors reaches and passes "Upper Critical" then the Shelf Manager
initiates a shutdown on the over-heated CNTL card.
Polycom, Inc.
In the Hardware Monitor pane, right-click the MPMx entry and then select Properties.
Click Active Alarms.
24-10RealPresence Collaboration Server (RMX) 2000 MPMx80 Properties
(degrees) Centigrade, it triggers an "Upper Major" event.
°
Chapter 24-RMX Hardware Monitoring
24-39
