Figure 16-6 shows the cables connected to the RealPresence Collaboration Server
(RMX) 4000 rear panel, when one RTM ISDN and three RTM LAN cards are installed
providing IP and ISDN connectivity. The RTM ISDN card can be used for both ISDN and IP
calls and only one IP network Service is associated with each RTM LAN card.
Figure
In this case, up to four different IP Network Services can be defined - one for each RTM
LAN/RTM ISDN cards installed in the system.
If two LAN ports per each installed RTM LAN card are used, up to three additional
Network Services can be defined, bringing it to a total of up to 7 IP Network Services.
Several cards can be assigned to the same IP Network Service. The definition of the network
services attached to the RMX unit and which cards are assigned to each network service is
defined in the IP Network Service.
RealPresence Collaboration Server (RMX) 2000 Multiple Services
Configuration
Connecting the cables to the RTM IP:
The following cables are connected to the RTM IP on the rear panel of the RealPresence
Collaboration Server (RMX) 2000:
Table 16-33
RTM IP Port
LAN 1
Polycom, Inc.
LAN cable (Media &
Signaling) Network 4
Management
Network
16-6RealPresence Collaboration Server (RMX) 4000 Rear Panel with LAN and PRI cables
LAN Connections to the RTM IP
Description
–
PRI cable
Shelf Manage-
ment
Chapter 16-Network Services
LAN cable
(Media & Sig-
naling)
Network 3
LAN cable
(Media & Sig-
naling)
Network 2
LAN cable
(Media & Sig-
naling)
Network 1
16-61
