Each trap is sent with a time stamp, the agent address, and the manager address.

Status Trap

The MCU sends status traps for the status MAJOR - a trap is sent when the card/MCU
status is MAJOR.
All traps are considered "MAJOR".
RMX MIB entities that do not generate traps.
The following table lists the entities that appear in the RMX MIB of the SNMP that do not
generate traps. These traps will be displayed as Faults in the System Alerts pane (at the
bottom of the Collaboration Server (RMX) Web Client screen.
Table 21-16
Key
5002
5004
5008
5009
5010
5014
Polycom, Inc.
Alarm Fault trap. The third trap type is a family of traps defined in the POLYCOM-
RMX-MIB file, these traps are associated with the RMX active alarm and clearance
(proprietary SNMP trap).
rmxFailedConfigUserListInLinuxAlarmFault notification received
from: 172.22.189.154 at 5/20/2007 7:04:22 PM
Time stamp: 0 days 00h:01m:11s.71th
Agent address: 172.22.189.154 Port: 32777 Transport: IP/UDP
Protocol: SNMPv2c Notification
Manager address: 172.22.172.34 Port: 162 Transport: IP/UDP
Community: public
Bindings (6)
Binding #1: sysUpTime.0 *** (timeticks) 0 days
00h:01m:11s.71th
Binding #2: snmpTrapOID.0 *** (oid)
rmxFailedConfigUserListInLinuxAlarmFault
Binding #3: rmxAlarmDescription *** (octets) Insufficient
resources
Binding #4: rmxActiveAlarmDateAndTime *** (octets) 2007-6-
19,16:7:15.0,0:0
Binding #5: rmxActiveAlarmIndex *** (gauge32) 2
Binding #6: rmxActiveAlarmListName *** (octets) Active
Alarm Table
* Binding #7: rmxActiveAlarmRmxStatus *** (rmxStatus) major
Figure 3 An Example of an Alarm Fault Trap
SNMP MIB entities that do not generate traps
Description
Resource process did not receive the Meeting Room list during
startup.
Task terminated
Low Processing Memory
Low system Memory
High system CPU usage
High CPU utilization
