Polycom RealPresence 4000 Administrator's Manual page 831

Polycom, Inc.
Both IPv4 and IPv6 addresses are supported and the system will only allow an entry of
the type of IP addresses for which the Management Network Service is configured
according to Table 23-14.
Table 23-14 IP Address Modes
IP Address Modes
RMX
IPv4
IPv6
IPv4 & IPv6
— If the system changes its IP addressing mode (e.g. from IPv4 only to both IPv4 &6)
while the White List is enabled, the White List is disabled and a message, White list
has been disabled please reconfigure, is displayed.
— IPv4 addresses can be added as a range by using the wildcard character, *, to
substitute the 3rd and 4th dotted decimal numbers of the IP address, e.g. 11.10.*.*
To Add IP addresses:
a
For each IP address to be added to the White List:
i) In the Add IP Address field enter an IP address to be added to the White List and
click the Add button.
If an invalid IP address is entered, an error message is displayed and the
administrator is prompted to enter a correct IP address.
If a duplicate IP address is entered, a message: Duplicate IP's are not allowed in
WhiteList is displayed.
ii) When all the IP addresses have been added, click OK.
A message is displayed: Applying white list will limit RMX web access to the
configured IP list, are you sure you want to continue?
iii) Click Yes to apply the modified White List.
b To Remove IP addresses:
For each IP address to be removed from the White List:
i) In the White List, click to select an IP address to be removed from the White
List.
ii) Click the Remove button.
ii) When all the IP necessary addresses have been removed, click OK.
A message is displayed: Applying white list will limit RMX web access to the
configured IP list, are you sure you want to continue?
iii) Click Yes to apply the modified White List.
Workstation / Device
IPv4
IPv4 & IPv6
IPv6
IPv4 & IPv6
IPv4
IPv6
IPv4 & IPv6
Chapter 23-Ultra Secure Mode
23-49
