Polycom RealPresence 4000 Administrator's Manual page 873

5
Run a "Diagnostics" test on a CTNL card by clicking the CTNL hardware component that indicates
"Diagnostics" in the status column.
6
Optional. In the Diagnostics - Active Test box you can select specific tests to run and then click Run
Selected Tests.
Polycom, Inc.
Diagnostics Test Monitoring
Figure 24-4 RealPresence Collaboration Server (RMX) 1500 Diagnostics Tests & Monitoring
Tests
When the RMX enters "Diagnostics Mode", the status MPM+/MPMx, CNTL/CNTL
1500/CNTL 4000 and RTM IP/RTM IP 1500/RTM IP 4000 changes to "Diagnostics".
You can run "Diagnostics" tests on a MPM+/MPMx card by double clicking any one of
the hardware components indicating "Diagnostics" in the status column.
Figure 24-5 RealPresence Collaboration Server (RMX) 2000/4000 MPMx D - DSP DSP Sub Test
selection
Select the Run all Tests box and then click Run Selected Tests.
Table 24-20 Tests Selection - Additional Test Parameters
Parameter
Loop Test
Stop On Failure
Description
Enter the amount of times the test is to repeat itself in succession.
Stops tests upon a failure.
Chapter 24-RMX Hardware Monitoring
Run all Test
Selection
24-31
