Signaling and Management Redundancy

RealPresence Collaboration Server (RMX) 1500
On the RealPresence Collaboration Server (RMX) 1500, for Signaling and Management
Redundancy, the MNG port is redundant to the MNG B port and must have a LAN cable
connected.
Figure
RealPresence Collaboration Server (RMX) 4000
On the RealPresence Collaboration Server (RMX) 4000, for Signaling and Management
Redundancy when LAN_REDUNDANCY = YES and MULTIPLE_SERVICES = NO, the LAN
3 port on the RTM-IP 4000 card is redundant to the LAN 2 port.
LAN ports 4 and 5 are never used.
Figure
On the RealPresence Collaboration Server (RMX) 1500/RealPresence Collaboration Server
(RMX) 4000 Signaling and Management Redundancy is implemented using the LAN ports on
the RTM-IP card and is dependent on the settings of the LAN_REDUNDANCY and
MULTIPLE_SERVICES System Flags as summarized in Table 1-2
Table 16-21
Flag / Value
LAN_REDUNDANCY
MULTIPLE_SERVICES = NO
LAN_REDUNDANCY
MULTIPLE_SERVICES = YES
LAN_REDUNDANCY
MULTIPLE_SERVICES = NO
Polycom, Inc.
Redundant ports
MNG MNG B
16-3RealPresence Collaboration Server (RMX) 1500 - RTM IP 1500 on Rear Panel
Redundant ports
LAN 2 LAN 3
16-4RealPresence Collaboration Server (RMX) 4000 - RTM IP 4000 on Rear Panel
RMX 1500 / 4000 - Signaling and Management Redundancy - System Flags
= NO
= NO
= YES
Port Usage
LAN 2 / MNG B )
(RMX 1500
Management
Management
Management & Signaling
(LAN3 is redundant to LAN 2)
Chapter 16-Network Services
LAN 3 / MNG
(RMX 1500)
Signaling
Not Used
16-39
