Polycom® RealPresence Collaboration Server (RMX) 1500/2000/4000 Administrator's Guide
2
3
4
To View the Supporting Hardware Components Properties:
1
24-14
Table 24-10 Card Properties - General Info (Continued)
Field
Serial Number
Card Type
Card Part Number
Card MAC Address 1
Card MAC Address 2
Click the Event Log tab to view a log of events that was recorded by the system on the
HW component.
For more information, see "MCU Properties - Event Log" on page 24-12.
Click the Active Alarms tab to view alarms related to the hardware component, i.e.
temperatures and main power sensors.
For more information, see "Active Alarms" on page 24-13.
Click Close to return to the HW Monitor pane.
In the Hardware Monitor pane, either double-click or right-click and select properties for
the desired supporting hardware component.
The component's properties dialog box will appear with the General Info tab displayed.
Backplane Properties:
The RMX unit's backplane properties provides the following information:
Table 24-11 Backplane Properties- General Info
Field
HW Version
SW Version
Serial Number
Description
The hardware component's serial number.
Displays the type of card that occupies the slot.
The part number of the HW component's board.
Specific hardware address of the component. This address is burnt
onto the component and is automatically identified by the system.
(If applicable) second Mac address.
Description
The Backplane's current hardware version.
The Backplane's current software version.
The Backplane's serial number.
