3
If you connected to the Hardware Monitoring via the Shelf Management server, the SW Alarm List
section will not be displayed.
To view the Card Properties:
1
Polycom, Inc.
Table 24-9 MCU Properties - Event Log (Continued)
Column
Ipmb Address(hex)
Click the Active Alarms tab to view alarms related to the RMX, i.e. temperatures and
main power sensors.
The Active Alarms dialog box displays fields that relate to faults and errors detected on
the RMX by sensors. The Active Alarms dialog box is divided into two sections: HW
Alarm List and SW Alarm List.
Each section's alarm list can be saved as a *.xls file by clicking the Save HW Alarm List
and Save SW Alarm List buttons respectively. Each alarm list color codes the severity
of the alarm; Critical (RED), Major (ORANGE) and Normal (GREEN).
In the Hardware Monitor pane, either double-click or right-click and select properties for
the desired hardware component.
The following information is displayed:
Table 24-10 Card Properties - General Info
Field
HW Version
SW Version
Description
Contains all the internal IPMI network addresses on the IPMB bus,
i.e. 0x20 (Switch), 0x86 (MFA), etc...
Description
The hardware component's version number.
The version number of the software installed on card.
Chapter 24-RMX Hardware Monitoring
24-13
