RealPresence Collaboration Server (RMX) 1500/2000/4000 Administrator's Guide
Table I-1
Component
Exchange 2007
R2 SP3
Exchange 2010
SP2
Outlook 2007
Outlook 2010
TIP Layout Support & Resource Usage
Cisco Telepresence endpoints using TIP protocol support only one (CTS 1000) or three (CTS
3000) display screens. Therefore, Polycom Telepresence endpoints will adjust their display
to use one or three screens as follows:
•
•
•
•
•
The Polycom MLA Server manages the conference template layouts for Telepresence
systems.
The number of screens used by each TIP-enabled endpoint is determined during the
capabilities exchange phase of the dial-in connection. It affects the usage and allocation of
resources used with TIP-enabled endpoints.
Supported TIP Resolutions and Resource Allocation
Supported Resolutions
In a Telepresence TIP-enabled environment, only two video resolutions are available:
720p30 & 1080p30.
Table I-2
Conference Line Rate
3Mb or higher
963kbps to 3Mb
Up to 936kbps
I-34
Solution Architecture Components
Version
8.3.213.1
14.2.247.5
12.0.6557.50
01 SP2
14.0.6112.50
00
OTX system - works with three screens, therefore no adjustment is required and it
should be set to work in room switch Telepresence Layout Mode (while avoiding
zooming in/out)
RPX 2xx - This endpoint works with two screens, therefore it will adjust to use only one
screen.
RPX 4xx - This endpoint works with four screens, therefore it will adjust to use only
three screens.
Standalone HDX - behaves as the CTS 1000 and uses only one screen.
Group system 300/500 - behaves as the CTS 1000 and uses only one screen.
Supported resolution per conference line rate
Description
Selected Resolution
1080p 30 fps
720p 30 fps
Call is disconnected.
