SNMP (Simple Network Management Protocol)

SNMP enables managing and monitoring of the MCU status by external managing systems,
such as HP OpenView or through web applications.
The RMX's implementation of SNMPv3 is FIPS 140 compliant.
MIBs (Management Information Base)
MIBs are a collection of definitions, which define the properties of the managed object
within the device to be managed. Every managed device keeps a database of values for each
of the definitions written in the MIB.
The SNMP systems poll the MCU according to the MIB definitions.
Traps
The MCU is able to send Traps to different managers. Traps are messages that are sent by
the MCU to the SNMP Manager when an event such as MCU Reset occurs.
Guidelines
•
•
•
•
MIB Files
The H.341 standard defines the MIBs that H.320 and H.323 MCUs must comply with. In
addition, other MIBs should also be supported, such as MIB-II and the ENTITY MIB, which
are common to all network entities.
The MIBs are contained in files in the SNMP MIBS sub-directory of the RMX root directory.
The files should be loaded to the SNMP external system and compiled within that
application. Only then can the SNMP external application perform the required monitoring
tasks.
The MULTI-MEDIA_MIB_TC must be compiled before compiling the other MIBs.
Private MIBs
•
21-30
Version 1, Version 2 and Version 3 traps are supported.
When SNMPv3 is selected only SNMPv3 Queries and Traps receive responses.
A mixture of Version 1, Version 2 and Version 3 traps is not permitted.
In Ultra Secure Mode:
— Version 3 is the default for both SNMP Agent Version and SNMP Trap Version.
— The default Authentication Protocol is SHA
— The default Privacy Protocol is AES.
RMX-MIB (RMX-MIB.MIB)
— Contains the statuses of the RMX: Startup, Normal and Major.
— Contains all the Alarms of the RMX that are sent to the SNMP Manager.
