Table I-1
Component
ASR (Cisco SBC)
Polycom Equipment
DMA
RMX
MLA Server
HDX and ITP
Endpoints
Microsoft
OCS 2007 R2
Lync 2010
OC 2007 R2
client
Lync 2010 client
Polycom, Inc.
Solution Architecture Components
Version
100x
6.0.0_ATT_B
uild_25
8.1.1
3.0.5
3.1.1.1
3.5.6907.236
4.0.7577.183
CU4
3.5.6907.236
4.0.7577.405
1 CU4
Appendix I-Polycom Open Collaboration Network (POCN)
Description
The Cisco Aggregation Services Routers (ASR) Series
includes Cisco IOS XE Software Internetwork Operating
System - Gatekeeper.
It controls and manages real-time multimedia traffic flows
between IP/SIP network borders, handling signaling,
data, voice, and video traffic.
Polycom Distributed Media Application
•
DMA is an optional component but is essential if
Content sharing is to be enabled.
•
All SIP endpoints register to DMA as a SIP Proxy.
•
DMA should be configured to route SIP calls (with
CTS destination) to CUCM.
•
DMA can be configured with a VMR (Virtual Meeting
Room). Incoming calls are then routed to the RMX.
MCU:
•
Functions as the network bridge for multipoint calls
between H.323, SIP and TIP endpoints.
•
The RMX can be interfaced to CUCM using a SIP
trunk, enabling CTS to join multipoint calls on RMX.
Signaling goes through the CUCM while the media in
TIP format goes directly between the CTS and RMX.
•
The RMX must be configured to route outbound SIP
calls to DMA.
•
RMX must be configured to send and receive RTP
streams to and from the Service Provider's SBC.
Multipoint Layout Application
Required for managing multi-screen endpoint layouts for
Cisco CTS 3XXX, Polycom TPX, RPX or OTX systems.
Telepresence, desktop and room systems.
•
Polycom SIP endpoints must register to DMA as SIP
Proxy.
I-33
