Rear Brakes

The drum brake assembly has a self shoe clearance adjusting system so that drum-to-shoe clearance is maintained

appropriate at all times. Rear brake is a drum type. It uses leading trailing operation when brake pedal is depressed

and when parking brake is applied on level road.

For components, refer to "Rear Drum Brake Assembly Components: ".

Replace all components included in repair kits to service this drum brake. Lubricate parts as specified.

If any hydraulic component is removed or brake line disconnected, bleed the brake system. The torque

values specified are for dry, unlubricated fasteners.

S5JB0A4301001
