Front Differential Components - Suzuki GRAND VITARA Owner's Manual

Remounting
Reverse dismounting procedure for remounting noting the following.
• Tighten each bolts and nuts referring to "Front Differential Unit Components: Front", "Front Drive Shaft Components:
Front in Section 3A" and "Front Suspension Frame, Stabilizer Bar and/or Bushings Components: in Section 2B".
• Fill front differential oil referring to "Front Differential Oil Change: Front".

Front Differential Components

18
(a)
19
5
3
6
7
8
1
1. Universal joint flange
2. Hypoid gear set
3. Bevel pinion spacer
4. Shim
5. Rear bearing
6. Front bearing
7. Oil seal
: Apply grease 99000-25010 to oil seal lip.
8. Flange nut
: After tightening nut so as rotation torque of bevel pinion shaft to be
in specified value, caulk nut securely.
15
20
4
2
9
A
14
16
11
17
10
11
10
12
17
14
16
22
(c)
26
13
15
20
17. Pinion washer
18. Retainer bolt
19. Differential side right retainer
: Apply sealant 99000-31260 to mating surface of right retainer,
carrier and rear cover.
20. Shim
21. Front drive shaft retainer
: Apply sealant 99000-31260 to mating surface of drive shaft
retainer, carrier and rear cover.
22. Bevel gear bolt
: Apply thread lock cement 99000-32110 to thread part of bolt.
23. Rear cover
24. Rear cover bolt No.1 bolt
Differential: Front 3B-4
S5JB0A3216001
(a)
25
24 (b)
23
18 (a)
21
I5JB0A321003-08
