Setting Measurement Conditions

(3) Circle window

Line type
Solid lines
Dotted lines
3
[How to set a circle window]
The following items on the settings menu can be used to define the circle window: CENTER, RAD.
Shown here is an example of how to define a solid line circle window.
1. Specifying the center
- Up key
2. Specifying the radius
- Up/right key

(4) Elliptical window

Line type
Solid lines
Dotted lines
[How to set an elliptical window]
The following items on the settings menu can be used to define the elliptical window: CENTER,
RAD. Shown here is an example of how to define a solid line elliptical window.
1. Specifying the center
- Up key
2. Specifying the radius
- Up key
Image processing used
Window containing a
Area measurement by binary conversion, object counting by
binary image
binary conversion, object identification by binary conversion
Area measurement by binary conversion, object counting by
Binary image window
mask
binary conversion, object identification by binary conversion
- Down key
- Down/left key
Image processing used
Window containing a
binary image
Binary image window
mask
- Down key
- Down key
Measurement programs
- Left key
- Right key
Measurement programs
Area measurement by binary conversion, object counting by
binary conversion, object identification by binary conversion
Area measurement by binary conversion, object counting by
binary conversion, object identification by binary conversion
- Left key
- Right key
- Left key
- Right key
3-6
