PC Function

16-4 Examples of a final output conditions ladder circuit

(1) Circuit for keeping the external output ON until the next external trigger is received
External trigger input
(2) Circuit for controlling the ON time of the external output using the timer
External trigger input
(3) An example of a circuit that can output a signal when the IV-S30 is operating normally.
16
C119
Measurement
termination
READY
External output
Y00)
C119
Measurement
termination
C119
READY
External output
Y00)
C110
Normally OFF
Start the system
Y00
C000
OK
TM0
C000
OK
100ms
Y00
Output while operation is normal
System error
Restart the system
The system will restart automatically
if it detects a system error.
16-18
Y00
NG output
TM0
10ms 10 100ms
0010
Y00
NG output
