1-9 Operation flow

[1] Power ON and main loop processing

(Power ON)
Wait to complete the power ON process
Initializing (CPU, gate array)
Memory check
Transmitting from flash memory to RAM
Data setting
- CPU, variables
- Gate array
Checksum checking
No
Settings for all types completed
Transmitting from flash memory to RAM
Obtaining images, capturing
specific lines of an image
ESC key
To the next page
- System program
- Conditions other than
the conditions specified
for each object type
NG
OK
Display check sum results
Yes
Measurement conditions for
each object type
ON
Place the MAIN OPS MENU
OFF
in the locked state
1-23
Setting and Operating Outline
Processing after the
power is turned ON
1
